Source: 600W CW LED
Field angle：2～52°
CRI: 72 / 95 （Freedom to switch）
High Brightness Mode: 23000 Lm
High CRI Mode: 15000 Lm
Beams, Spot, Wash, Frame
Rotation gobo: 7 + 1
Color wheel：7 + 1 / CMY / CTO
Prism：6 linear+8 prism
Lightweight alloy shell, low overall weight
Source: 600W CW LED
High Brightness Mode: 23000 Lm
High CRI Mode: 15000 Lm
CRI: 72 / 95 （Freedom to switch）
Field angle： 2～52°
CT：6500 K
Source lifetime：>20000 H
Strobe：1～25Hz
Rotation gobo: 7 + 1
Rotation gobo wheel 1：7+1
Fixed gobo wheel：8+1
Color wheel：7+ 1
Linear CMY
Linear CTO（2400~6500K）
Prism：6 linear+8 prism
Frost: 2，1 light +1 heavy
Framing: With 4 blade, can achieve fast and smooth cutting. The framing direction and angle of each blade can be controlled separately, and the each brade can realize complete beam closing. The whole cutting module can be rotated by ±60°
Animation + With iris
Channel：46 / 60CH
Protocal：DMX512, RDM, Artnet, sACN
Data connector：3 PIN (or 5 PIN) XLR，RJ45
Display: 2.8 inches touch screen, the operation panel has a rechargeable battery that allows you to access the menu to set the address code and make other settings without power on
NFC: The lighting fixtures do not require power on and can be directly set up, diagnosed, and perform other functions through the CKC app
Via USB & DMX signal to update
Static waterproof fan intelligent speed control
Intelligent temperature protection to ensure LED service life
Pan: 540° or 630° 8bit/16bit
Tilt: 270° 8bit/16bit
Aluminum alloy structure + plastic (VO)
Fan cooling
Resistant to salt corrosion
IP rating: IP66
Work environment: -40℃ ~ 45℃
Startup environment: -20℃ ~ 45℃
Voltage: AC 100V~240V 50/60Hz
Rated power：990W
Size：398×281×677 mm
N.W：30 kgs
